GYS Autopulse 220-M3 Mig Welder


AUTOPULSE 220-M3 is the MIG / MAG pulse generator with 3 integrated wire feeders ideal for car body repairers.

Product Description:

S&S Industries is the premier Spray Booth, Panel and Paint Supplier located in Western Australia, Midvale.

AUTOPULSE 220-M3 is the MIG / MAG pulse generator with 3 integrated wire feeders ideal for car body repairers. Equipped with a digital PFC (Power Factor Correction) the Autopulse supplies pulsed welding quality comparable to three-phase products. Designed for the highest performance the 220-M3 features several synergic curves which enable exceptional arc quality. The Autopulse 220-M3 is incredibly versatile, 3 welding torches for use with multiple materials including Steel, Aluminium, and Brazing (CuSi3/CuAl8) increase productivity for the modern day workshop.

The intuitive interface and high precision wire feed are ideal for car-body applications with exceptional welding quality even when used with thin sheet materials.

Welding processes: Standard, Pulse, Pulse in Pulse, Cold pulse, and Manual.
Trigger modes: 2T, 4T, SPOT, DELAY, and TACK function.
Precise control over the welding cycle: CreepSpeed, Softstart, Hotstart, Upslope, Downslope, Crater Fill, Post gas, etc.

2 specific compartments to isolate and avoid pollution of the aluminum coil:
- steel wire Ø 0.6 / 0.8 / 1.0 mm (upper compartment n ° 1)
- stainless steel wire Ø 0.8 / 1.0 mm (upper compartment n ° 1)
- aluminum wire Ø 0.8 / 1.0 / 1.2 (lower compartment n ° 2)
- CuSi and CuAl wire Ø 0.8 / 1.0 mm (upper compartment n ° 1)

57 (Adjustable) synergic curves ensure an outstanding weld for a large range of materials, wire sizes and gas.
The fully synergic mode calculates the optimal welding parameters automatically, this can be also be adjusted (wire speed, voltage and current).

4 microprocessors to give four times the processing power.
3 wheel drive system with 2 active drive rolls.
Up to 3 wire reels of Ø 200 mm accepted.
Automatic torch detection while pulling the trigger.
Balancing arm with torch support (x3) and welding helmet
Push pull torch compatibilty (24V)
Spool Gun compatibility (ideal for soft wire(AlSi5 / AlSi12)

Brand new Interface which has been simplified and centralized with car-body repairer operational habits.
Large colour screen for simple control of the welding cycle set up.
2 control knobs and 4 keys for simple and intuitive navigation of the operational menus.
Machine and synergies easily updateable via USB key.
Save up to 500 welding programs for repetitive tasks.

Reinforced structure.
Frame supporting 2 bottles (2x4m3) with low loading height.

Contact us today for help from our specialist with your next purchase.

Please note: We can only sell this item within Western Australia.
